Juniper EX4300 Hardware Guide

CHAPTER 17
Replacing Uplink Module
•
Installing an Uplink Module in an EX4300 Switch on page 241
•
Removing an Uplink Module from an EX4300 Switch on page 243
Installing an Uplink Module in an EX4300 Switch
You can install an uplink module in the front panel of an EX4300 switch. The uplink
module in EX4300 switches is a hot-removable and hot-insertable unit (FRU): You can
remove and replace it without powering off the switch.
NOTE: If you have set an uplink module port as a Virtual Chassis port (VCP),
removing the uplink module breaks the setting. You must reset the port as a
VCP after you replace the module. See Setting an Uplink Port on an EX Series
Switch as a Virtual Chassis Port (CLI Procedure).
Before you begin installing an uplink module in the switch:
•
Ensure that you have taken the necessary precautions to prevent ESD damage (see
“Prevention of Electrostatic Discharge Damage” on page 313).
Ensure that you have the following parts and tools available:
•
Electrostatic discharge (ESD) grounding strap (If a grounding strap is not available,
follow the alternativegrounding method described in Step 1 of the following procedure.)
•
Phillips (+) screwdriver, number 2
241Copyright © 2017, Juniper Networks, Inc.

Juniper EX4300 Specifications

General

Model	EX4300
Virtual Chassis	Yes, up to 10 members
Layer 3 Routing	Yes
10GBASE SFP+ Ports	4
Jumbo Frames	9216 bytes
MAC Address Table Size	32, 000
Operating System	Junos OS
Uplink Ports	4 x 10GBASE SFP+
Power Supply	AC or DC options
Operating Temperature	0°C to 45°C (32°F to 113°F)
Input Voltage	100-240V AC
Operating Relative Humidity	5 to 90% RH, non-condensing
Management Options	CLI, Web UI, Junos Space
Redundancy	Yes, power supply and fans
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Ports	24 or 48
