Table 12: LCD Panel Menu Options in EX4300 Switches
DescriptionMenu Label
In the Idle menu:
Press Enter to cycle through the Status LED modes, which are port status indicators:
ADM (administrative status)
DPX (duplex)
SPD (speed)
POE (Power over Ethernet) (only for EX4300-24P, EX4300-24P-S,EX4300-48P, and EX4300-48P-S
models)
See “Network Port, Built-In QSFP+ Port, Uplink Port, and Uplink Module Port LEDs on EX4300 Switches”
on page 39 for information about the Status LED modes.
Press Menu to exit the Idle menu and go to the Status menu.
IDLE
In the Status menu, press Menu to cycle through the following information:
VCPs status: Up or Down
Display the status of VCPs on the switch. This option is supported only on EX4300 switches in a Virtual
Chassis configuration. This option is not supported on standalone EX4300 switches.
Power supply status: OK, Failed, or Absent
Fan status and Temperature status.
Fan status: OK, Failed, or Absent
Temp status: OK, High, or Shutdown
Junos OS version for EX Series switches loaded on the switches.
EXIT STAT MENU?
Choose one of the following:
Press Enter to exit the Status menu and go to the Maintenance menu.
Press Menu to display the VCPs status again.
You can disable the Status menu or the options in the Status menu in the LCD panel. See “Configuring the
LCD Panel on EX Series Switches (CLI Procedure)” on page 223.
STATUS
Copyright © 2017, Juniper Networks, Inc.30
EX4300 Switch Hardware Guide
