Juniper EX4300 Hardware Guide

Table 6: Uplink Modules for 24-Port and 48-Port EX4300 Switches
First Junos OS
ReleaseSupported EX4300 Switch ModelsDescriptionUplink Module
13.2X50-D10
•
EX4300-24T
•
EX4300-24P
•
EX4300-48T
•
EX4300-48T-AFI
•
EX4300-48P
•
EX4300-48T-DC
•
EX4300-48T-DC-AFI
The 4-port SFP+ uplink module can
house up to four SFP+ transceivers,
SFP transceivers, or a combination of
SFP+ and SFP transceivers. You can
also configure ports on this module
as VCPs and use them to connect the
switch in a Virtual Chassis or a VCF
configuration by using SFP+
transceivers.
4-port 10-Gigabit
Ethernet SFP+
uplink module
13.2X51-D26
•
EX4300-24T-S
•
EX4300-24P-S
•
EX4300-48T-S
•
EX4300-48P-S
Table 7: Uplink Modules for 32-Port EX4300 Switches
First Junos OS
Release
Supported EX4300 Switch
ModelsDescriptionUplink Module
13.2X51-D15
•
EX4300-32F
•
EX4300-32F-DC
The QSFP+ uplink module can house up to
two QSFP+ transceivers. You can also
configure the ports on this module as VCPs
and use them to connect the switch in a
Virtual Chassis or a VCF configuration.
2-port 40-Gigabit
Ethernet QSFP+
uplink module
13.2X51-D26
•
EX4300-32F-S
13.2X51-D15
•
EX4300-32F
•
EX4300-32F-DC
The 8-port SFP+ uplink module can house
up to eight SFP+ transceivers, SFP
transceivers, or a combination of SFP+ and
SFP transceivers. You can also configure the
ports on this module as VCPs and use them
to connect the switch in a Virtual Chassis or
a VCF configuration by using SFP+
transceivers.
8-port 10-Gigabit
Ethernet SFP+
uplink module
13.2X51-D26
•
EX4300-32F-S
For more information about uplink modules, see “Uplink Modules in EX4300 Switches”
on page 31.
Virtual Chassis
You can interconnect a maximum of 10 EX4300 switches to form a Virtual Chassis. You
can operate these interconnected switches as a single, logical device with a single IP
address.
You can use the following ports to configure an EX4300 switch in a Virtual Chassis:
•
For 24-port and 48-port EX4300 switches:
•
QSFP+ ports configured as VCPs
•
SFP+ uplink module ports configured as VCPs
Copyright © 2017, Juniper Networks, Inc.10
EX4300 Switch Hardware Guide

Juniper EX4300 Specifications

General

Model	EX4300
Virtual Chassis	Yes, up to 10 members
Layer 3 Routing	Yes
10GBASE SFP+ Ports	4
Jumbo Frames	9216 bytes
MAC Address Table Size	32, 000
Operating System	Junos OS
Uplink Ports	4 x 10GBASE SFP+
Power Supply	AC or DC options
Operating Temperature	0°C to 45°C (32°F to 113°F)
Input Voltage	100-240V AC
Operating Relative Humidity	5 to 90% RH, non-condensing
Management Options	CLI, Web UI, Junos Space
Redundancy	Yes, power supply and fans
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Ports	24 or 48
