Table 16: Uplink Modules Used in 32-Port EX4300 Switches
FigureModel NumberUplink Module Name
Figure 15: 2-Port 40-Gigabit Ethernet
QSFP+ Uplink Module
Figure 16: LEDs on the 2-Port 40-Gigabit
Ethernet QSFP+ Uplink Module
1. Status LED of the uplink module
2. Link activity LED of the uplink module port
3. Status LED of the uplink module port
EX-UM-2QSFP2-port 40-Gigabit Ethernet
QSFP+ uplink module
Copyright © 2017, Juniper Networks, Inc.34
EX4300 Switch Hardware Guide
