Juniper EX4300 Hardware Guide

Figure 76: Removing a 4-Port SFP+ Uplink Module from a 24-Port or
48-Port EX4300 Switch
Figure 77: Removing a 2-Port QSFP+ Uplink Module from a 32-Port
EX4300 Switch
Figure 78: Removing an 8-Port SFP+ Uplink Module from a 32-Port
EX4300 Switch
Related
Documentation
• Installing an Uplink Module in an EX4300 Switch on page 241
• Installing and Removing EX4300 Switch Hardware Components on page 176
• Field-Replaceable Units in EX4300 Switches on page 26
• EX4300 Switches Hardware Overview on page 3
245Copyright © 2017, Juniper Networks, Inc.
Chapter 17: Replacing Uplink Module

Juniper EX4300 Specifications

General

Model	EX4300
Virtual Chassis	Yes, up to 10 members
Layer 3 Routing	Yes
10GBASE SFP+ Ports	4
Jumbo Frames	9216 bytes
MAC Address Table Size	32, 000
Operating System	Junos OS
Uplink Ports	4 x 10GBASE SFP+
Power Supply	AC or DC options
Operating Temperature	0°C to 45°C (32°F to 113°F)
Input Voltage	100-240V AC
Operating Relative Humidity	5 to 90% RH, non-condensing
Management Options	CLI, Web UI, Junos Space
Redundancy	Yes, power supply and fans
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Ports	24 or 48
