Page #47 background image
CHAPTER 2
Chassis Components and Descriptions
Chassis Physical Specifications for EX4300 Switches on page 25
Field-Replaceable Units in EX4300 Switches on page 26
LCD Panel in EX4300 Switches on page 27
Uplink Modules in EX4300 Switches on page 31
Chassis Status LEDs on EX4300 Switches on page 36
Management Port LEDs on EX4300 Switches on page 38
Network Port, Built-InQSFP+ Port, Uplink Port,and Uplink Module Port LEDs on EX4300
Switches on page 39
Chassis Physical Specifications for EX4300 Switches
The EX4300 switch chassis is a rigid sheet-metal structure that houses all components
of the switch. Table 11 on page 25 summarizes the physical specifications of the EX4300
switch chassis.
Table 11: Physical Specifications of the EX4300 Switch Chassis
ValueDescription
1.72 in. (4.37 cm)Chassis height
17.36 in. (44.09 cm)
The outer edges of the front-mounting brackets extend the width to 19 in. (48.2 cm)
Chassis width
16.38 in. (41.61 cm)
With power supply and uplink module installed: 18.01 in. (45.76 cm)
Chassis depth
EX4300 switch (with no power supply and no fan module installed): 13 lb (5.9 kg)
350 W AC power supply: 2.4 lb (1.1 kg)
550 W DC power supply: 2.4 lb (1.1 kg)
715 W AC power supply: 2.4 lb (1.1 kg)
1100 W AC power supply: 2.4 lb (1.1 kg)
QSFP+ uplink module: 0.61 lb (0.28 kg)
4-port SFP+ uplink module: 0.44 lb (0.2 kg)
8-port SFP+ uplink module: 0.74 lb (0.34 kg)
Fan module: 0.33 lb (0.15 kg)
Weight
25Copyright © 2017, Juniper Networks, Inc.
