Juniper EX4300 Hardware Guide

CHAPTER 10
Unpacking the Switch
•
Unpacking an EX4300 Switch on page 161
•
Parts Inventory (Packing List) for an EX4300 Switch on page 162
•
Registering Products—Mandatory for Validating SLAs on page 163
Unpacking an EX4300 Switch
EX4300 switches are shipped in a cardboard carton, securedwith foam packing material.
The carton has an accessory compartment and contains the quick start instructions.
CAUTION: EX4300 switches are maximally protected inside the shipping
carton. Do not unpack the switches until you are ready to begin installation.
To unpack the switch:
1. Move the shipping carton to a staging area as close to the installation site as possible,
but where you have enough room to remove the system components.
2. Position the carton so that the arrows are pointing up.
3. Open the top flaps on the shipping carton.
4. Pull out the packing material holding the switch in place.
5. Verify the parts received against the inventory on the label attached to the carton.
See “Parts Inventory (Packing List) for an EX4300 Switch” on page 162.
6. Save the shipping carton and packing materials in case you need to move or ship the
switch later.
Related
Documentation
Installing and Connecting an EX4300 Switch on page 165•
• Connecting and Configuring an EX Series Switch (CLI Procedure) on page 215
• Connecting and Configuring an EX Series Switch (J-Web Procedure) on page 218
161Copyright © 2017, Juniper Networks, Inc.

Juniper EX4300 Specifications

General

Model	EX4300
Virtual Chassis	Yes, up to 10 members
Layer 3 Routing	Yes
10GBASE SFP+ Ports	4
Jumbo Frames	9216 bytes
MAC Address Table Size	32, 000
Operating System	Junos OS
Uplink Ports	4 x 10GBASE SFP+
Power Supply	AC or DC options
Operating Temperature	0°C to 45°C (32°F to 113°F)
Input Voltage	100-240V AC
Operating Relative Humidity	5 to 90% RH, non-condensing
Management Options	CLI, Web UI, Junos Space
Redundancy	Yes, power supply and fans
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Ports	24 or 48
