Juniper EX4300 Hardware Guide

Table 3: Components in 24-Port EX4300 Switches (continued)
Supported
Uplink
Module
Power Supply
Shipped by Default
Fan Modules
Shipped by Default
Number of
PoE-enabled
PortsBuilt-In PortsSwitch Models
4-port
10-Gigabit
Ethernet SFP+
uplink module
Power supplies for
this model are not
shipped by default;
you must separately
order either AC power
supplies or DC power
supplies.
Fan modules for this
model are not shipped
by default; you must
separately order either
two AIR OUT (AFO)
labeled or two AIR IN
(AFI) labeled fan
modules.
2424
10/100/1000BASE-T
Ethernet ports and
four QSFP+ ports
EX4300-24P-S
You can use the QSFP+ ports as network ports or as Virtual Chassis ports (VCPs) to
connect the switch in a Virtual Chassis or a VCF. By default, the built-in QSFP+ ports are
configured as VCPs. You can also use the uplink module ports to connect members of a
Virtual Chassis or a VCF across multiple wiring closets by configuring the ports as VCPs.
For more information about Virtual Chassis, see EX Series Virtual Chassis Overview. For
more information about VCFs, see Virtual Chassis Fabric Overview.
32-Port EX4300 Switches
The 32-port EX4300 switches—EX4300-32F and EX4300-32F-DC—provide 32 built-in
1-Gigabit Ethernet small form-factor pluggable (SFP) network ports that can house SFP
transceivers, four built-in 10-Gigabit Ethernet small form-factor pluggable plus (SFP+)
ports thatcan house SFP+ and SFP transceivers, and twobuilt-in quad small form-factor
pluggable plus (QSFP+) ports that can house 40-Gigabit QSFP+ transceivers. They
support power supply and fan module with front-to-back airflow direction and have a
slot for installing an optional uplink module—a 2-port 40-Gigabit Ethernet QSFP+ uplink
module that can house two QSFP+ transceivers or an 8-port 10-Gigabit Ethernet SFP+
uplink module that can house eight SFP+ transceivers, eight SFP transceivers, or a
combination of eight SFP+ and SFP transceivers.
Figure 3 on page 6 shows the front panel of a 32-port EX4300 switch.
Figure 3: Front Panel of a 32-Port EX4300 Switch
Figure 4 on page 7 shows the rear panel of a 32-port EX4300 switch.
Copyright © 2017, Juniper Networks, Inc.6
EX4300 Switch Hardware Guide

Juniper EX4300 Specifications

General

Model	EX4300
Virtual Chassis	Yes, up to 10 members
Layer 3 Routing	Yes
10GBASE SFP+ Ports	4
Jumbo Frames	9216 bytes
MAC Address Table Size	32, 000
Operating System	Junos OS
Uplink Ports	4 x 10GBASE SFP+
Power Supply	AC or DC options
Operating Temperature	0°C to 45°C (32°F to 113°F)
Input Voltage	100-240V AC
Operating Relative Humidity	5 to 90% RH, non-condensing
Management Options	CLI, Web UI, Junos Space
Redundancy	Yes, power supply and fans
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Ports	24 or 48
