Page #178 background image

Loading...

Page #178 background image

Table 84: QSFP+ Network Port Connector Pinout Information (continued)

SignalPin

RX1p17

RX1n18

GND19

GND20

RX2n21

RX2p22

GND23

RX4n24

RX4p25

GND26

ModPrsL27

IntL28

VccTx29

Vcc130

Reserved31

GND32

TX3p33

TX3n34

GND35

TX1p36

TX1n37

GND38

Related

Documentation

Installing a Transceiver on page 247•

Copyright © 2017, Juniper Networks, Inc.156
