Read “General Safety Guidelines and Warnings” on page 283, with particular attention
to “Chassis Lifting Guidelines” on page 292.
•
Remove the switch from the shipping carton (see “Unpacking an EX4300 Switch” on
page 161).
Ensure that you have the following parts and tools available:
•
Phillips (+) screwdriver, number 2 (not provided)
•
2 wall-mount brackets (provided with the wall-mount kit)
•
12 wall-mount bracket screws (provided with the wall-mount kit)
•
4 mounting screws (8-32 x 1.25 in. or M4 x 30 mm) (not provided)
•
Cover panels for uplink module and power supply slots (provided)
•
Hollow wall anchors capable of supporting the combined weight of two fully loaded
switches, up to 33 lb (15 kg) (not included)—ifyou are mounting the switch in sheetrock
(wall board with a gypsum plaster core) or in wall board not backed by wall studs.
WARNING: When mounted in a vertical position, an EX4300 switch must be
oriented with the front panel of the chassis pointing down to ensure proper
airflow and meet safety requirements in the event of a fire.
NOTE: For easier lifting, install any additional power supplies only after you
mount the switch on the wall.
Copyright © 2017, Juniper Networks, Inc.174
EX4300 Switch Hardware Guide
