1.6 System Conguration and Part Name
z
Default settings for mini console keys
The roles of the button to which the SET
*
3
function is assigned and the FREEZE button do not change depending
on the image mode or functions being run when the buttons are pressed. Other key defaults are listed below.
Key B-mode M-mode
CFM / PDI / 2D-TDI /
SCF-mode
PW / CW /
PW-TDI-mode
Elastography-mode
EXIT
button
[Update] -
F2
*
3
button
Operation item switching
Rotate function
*
3
F2 Rotate 1 [Focus Position] [B Gain] [Angle Correct.] [Blend Ratio]
F2 Rotate 2 - [Ana-M Angle] - [Gate Size] -
Trackball Active function of operation item
F1
*
1
*
4
button
Switching of functions assigned to the dial
F1
*
1
*
6
dial
function1
[Depth] /
[Zoom Ratio]
(with Zoom enabled)
-
[Depth] /
[Zoom Ratio]
(with Zoom enabled)
[D Scale]
[Depth] /
[Zoom Ratio]
(with Zoom
enabled)
*
7
F1
*
1
*
6
dial
function2
[Focus
Position]
- [C Scale] [D Baseline]
[Focus
Position]
*
7
Gain
*
1
button
[Simple Adjust]
*
5
- [Simple Adjust]
*
5
[Simple Adjust]
*
5
[Simple Adjust]
*
5
Gain
*
1
dial
[B Gain] [M Gain] [C Gain] [D Gain] [B Gain]
User 1
button
[Dual L]
*
2
*
8
User 2
button
[Dual R]
*
2
*
8
