Kyocera FS-C8600DN Service Manual

2MN/2N1
1-3-42
U053 Setting: [Motor2]
1. Select the item to be adjusted.
Setting: [Motor3]
1. Select the item to be adjusted.
Item No. Description
Display Description
Setting
range
Initial setting
45ppm 55ppm
Dev(K) Developer motor K
(DEVM-K)
-5000 to 5000 0 0
Dev(CMY) Developer motor MCY
(DEVM-MCY)
-5000 to 5000 0 0
Trans Transfer motor (TRM) -5000 to 5000 0 0
Regist Registration motor (RM) -5000 to 5000 17 15
Clean Transfer cleaning motor
(TRCM)
-5000 to 5000 0 0
Display Description
Setting
range
Initial setting
45ppm 55ppm
SB Eject motor (EM) -5000 to 5000 27 -18
Fixing Fuser motor (FUM) -5000 to 5000 0 0
Brg1 BR conveying motor 1
(BRCM1)
-5000 to 5000 -30 -27
Brg2 BR conveying motor 2
(BRCM2)
-5000 to 5000 -30 -27
Feed Paper feed motor (PFM) -5000 to 5000 82 73
JobSepa JS eject motor (JSEM) -5000 to 5000 0 0
Mid Middle motor (MM) -5000 to 5000 18 16
DU1 Duplex motor 1 (DUM1) -5000 to 5000 -30 -27
DU2 Duplex motor 2 (DUM2) -5000 to 5000 -30 -27
Brg1 DF H BR conveying motor 1
(BRCM1)
-5000 to 5000 0 0
Brg1 DF L BR conveying motor 1
(BRCM1)
-5000 to 5000 0 0
Brg2 DF H BR conveying motor 2
(BRCM2)
-5000 to 5000 0 0
Brg2 DF L BR conveying motor 2
(BRCM2)
-5000 to 5000 0 0

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
