Kyocera FS-C8600DN Service Manual

2MN/2N1
1-3-43
U053 Setting: [Motor4]
1. Select the item to be adjusted.
*: 55 ppm model only.
Setting: [Motor5]:55 ppm model only
1. Select the item to be adjusted.
Setting: [Motor6]:55 ppm model only
1. Select the item to be adjusted.
Item No. Description
Display Description
Setting
range
Initial setting
45ppm 55ppm
Drum B/W
K
Drum motor K (DRM-K) in
black/white mode
-5000 to 5000 - 25
Drum-
Mono K
Drum motor K (DRM-K) in
monochrome mode
-5000 to 5000 28 22
Display Description
Setting
range
Initial
setting
Dev B/W(K)
Developer motor K (DEVM-K) in black/
white mode
-5000 to 5000 0
Trans B/W Transfer motor (TRM) in black/white
mode
-5000 to 5000 0
Regist B/W Registration motor (RM) in black/white
mode
-5000 to 5000 14
Clean B/W Transfer cleaning motor (TRCM) in
black/white mode
-5000 to 5000 0
Display Description
Setting
range
Initial
setting
SB B/W Eject motor (EM) in black/white mode -5000 to 5000 -16
Fixing B/W Fuser motor (FUM) in black/white
mode
-5000 to 5000 0
Brg1 B/W BR conveying motor 1 (BRCM1) in
black/white mode
-5000 to 5000 -25
Brg2 B/W BR conveying motor 2 (BRCM2) in
black/white mode
-5000 to 5000 -25
Feed B/W Paper feed motor (PFM) in black/white
mode
-5000 to 5000 66
JobSepaB/W JS eject motor (JSEM) in black/white
mode
-5000 to 5000 0
Mid B/W Middle motor (MM) in black/white mode -5000 to 5000 15
DU1 B/W Duplex motor 1 (DUM1) in black/white
mode
-5000 to 5000 -24
DU2 B/W Duplex motor 2 (DUM2) in black/white
mode
-5000 to 5000 -24

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
