Kyocera FS-C8600DN Service Manual

2MN/2N1
1-3-44
U053 Setting: [Motor1 Half]
1. Select the item to be adjusted.
Setting: [Motor2 Half]
1. Select the item to be adjusted.
Setting: [Motor3 Half]
Select the item to be adjusted.
Item No. Description
Display Description
Setting
range
Initial
setting
Drum(K) Drum motor K (DRM-K) in half speed -5000 to 5000 0
Display Description
Setting
range
Initial setting
45ppm 55ppm
Dev(K) Developer motor K
(DEVM-K) in half speed
-5000 to 5000 0 0
Dev(CMY) Developer motor MCY
(DEVM-MCY) in half
speed
-5000 to 5000 0 0
Trans Transfer motor (TRM) in
half speed
-5000 to 5000 0 0
Regist Registration motor (RM)
in half speed
-5000 to 5000 34 30
Clean Transfer cleaning motor
(TRCM) in half speed
-5000 to 5000 0 0
Display Description
Setting
range
Initial setting
45ppm 55ppm
SB Eject motor (EM) in half
speed
-5000 to 5000 54 -36
Fixing Fuser motor (FUM) in half
speed
-5000 to 5000 0 0
Brg1 BR conveying motor 1
(BRCM1) in half speed
-5000 to 5000 -43 -38
Brdg2 BR conveying motor 2
(BRCM2) in half speed
-5000 to 5000 -43 -38
Feed Paper feed motor (PFM)
in half speed
-5000 to 5000 164 147
JobSepa JS eject motor (JSEM) in
half speed
-5000 to 5000 0 0
Mid Middle motor (MM) in half
speed
-5000 to 5000 36 32
