Kyocera FS-C8600DN Service Manual

2MN/2N1
1-4-4
0211 SM paper conveying
cover open
The SM paper conveying cover is opened during print-
ing.
J
0212 SM top cover open The SM top cover is opened during printing. J
0213 SD cover open The SD cover is opened during printing. J
0214 PF paper conveying
cover (side) open
The PF paper conveying cover (side) is opened during
printing.
K
0215 Side multi tray release The side multi tray is released during printing. J
0300 Ejection uncompleted An ejection-completed error has occurred. -
0501 No paper feed from cas-
sette 1
Feed sensor 1 (FS1) does not turn on during paper
feed from cassette 1.
A
0502 No paper feed from cas-
sette 2
Feed sensor 2 (FS2) does not turn on during paper
feed from cassette 2.
B
0503 No paper feed from cas-
sette 3
PF feed sensor 1 (PFFS1) does not turn on during
paper feed from cassette 3 (paper feeder).
C
0504 No paper feed from cas-
sette 4
PF feed sensor 2 (PFFS2) does not turn on during
paper feed from cassette 4 (paper feeder).
C
0505 No paper feed from cas-
sette 5
SM feed sensor (SMFS) does not turn on during paper
feed from cassette 5 (side multi tray).
J
0506 No paper feed from cas-
sette 6
PF feed sensor 1 (PFFS1) does not turn on during
paper feed from cassette 6 (side paper feeder).
K
0507 No paper feed from cas-
sette 7
PF feed sensor 2 (PFFS2) does not turn on during
paper feed from cassette 7 (side paper feeder).
K
0508 No paper feed from
duplex section
Registration sensor (RS) does not turn on during paper
feed from duplex section.
F
0509 No paper feed from MP
tray
MP feed sensor (MPFS) does not turn on during paper
feed from MP tray.
D
0511 Multiple sheets in cas-
sette 1
Feed sensor 1 (FS1) does not turn off during paper
feed from cassette 1.
A
0512 Multiple sheets in cas-
sette 2
Feed sensor 2 (FS2) does not turn off during paper
feed from cassette 2.
B
0513 Multiple sheets in cas-
sette 3
PF feed sensor 1 (PFFS1) does not turn off during
paper feed from cassette 3 (paper feeder).
C
0514 Multiple sheets in cas-
sette 4
PF feed sensor 2 (PFFS2) does not turn off during
paper feed from cassette 4 (paper feeder).
C
Code Contents Conditions
Jam
loc
ation*
*: Refer to figure 1-4-1 for paper misfeed indication (see page 1-4-1).

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
