2MN/2N1-1
1-5-11
13. Remove two screws.
14. Remove the MP tray paper feed unit.
*: To reinstall the MP tray feed unit, align it
with the opening in the front left bottom
frame of the feed unit, install the MP
tray feed unit, and raise it so that it is
correctly seated.
Figure 1-5-16
MP tray
paper feed unit
Screw
Screw
MP tray
paper feed unit
To Next Page
