Kyocera FS-C8600DN Service Manual

2MN/2N1
2-3-11
YC4
17 CAS1_LNG3 I 0/3.3 V DC PLSW1: On/Off
Connected to
feed PWB 2
18 CAS1_LNG2 I 0/3.3 V DC PLSW1: On/Off
19 CAS1_LNG1 I 0/3.3 V DC PLSW1: On/Off
20 GND - - Ground
21 CAS2_QUANT2 I 0/3.3 V DC PGS2(L): On/Off
22 CAS2_QUANT1 I 0/3.3 V DC PGS2(U): On/Off
23 CAS1_QUANT2 I 0/3.3 V DC PGS1(L): On/Off
24 CAS1_QUANT1 I 0/3.3 V DC PGS1(U): On/Off
25 LIFT_MOT1_LOC
K
I 0/3.3 V DC LM1 lock signal
26 LIFT_MOT2_LOC
K
I 0/3.3 V DC LM2 lock signal
27 CURRENT_SIG I 0/3.3 V DC Current signal
28 V-FEED_CL O 0/24 V DC PCCL: On/Off
29 COVER_OPEN I 0/3.3 V DC PCCSW: On/Off
30 FEED2_SENS I 0/3.3 V DC PFPCS1: On/Off
31 CAS1_P0 I 0/3.3 V DC FS1: On/Off
32 CAS1_LIFT_UP I 0/3.3 V DC LS1: On/Off
33 GND - - Ground
34 CAS1_EMPTY I 0/3.3 V DC PS1: On/Off
35 PICK_SOL1_RET O 0/24 V DC PUSOL1: On/Off (RET)
36 PICK_SOL1_REM O 0/24 V DC PUSOL1: On/Off (ACT)
37 CAS2_P0 I 0/3.3 V DC FS2: On/Off
38 CAS2_LIFT_UP I 0/3.3 V DC LS2: On/Off
39 CAS2_EMPTY I 0/3.3 V DC PS2: On/Off
40 PICK_SOL2_RET O 0/24 V DC PUSOL2: On/Off (RET)
41 PICK_SOL2_REM O 0/24 V DC PUSOL2: On/Off (ACT)
42 GND - - Ground
43 REG_SENS I 0/3.3 V DC RS: On/Off
44 FEED1_SENS I 0/3.3 V DC PCS: On/Off
45 BEND_SENS I 0/3.3 V DC RDS: On/Off
46 MID_MOT_PH O 0/3.3 V DC MM control signal
47 MID_MOT_REM(
ROL_CL)
O 0/3.3 V DC MM/MCL: On/Off
48 MID_MOT_CLK O 0/3.3 V DC (pulse) MM clock signal
49 MID_MOT_PD O 0/3.3 V DC MM control signal
50 ASIST_CL1 O 0/24 V DC ASCL1: On/Off
Connector Pin Signal I/O Voltage Description

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
