2MN/2N1
2-3-10
YC3
A16 5V - - Ground
Connected to
transfer belt
unit
B1 GND - - Ground
B2 ZIG_SENS I 0/3.3 V DC TRSS: On/Off
B3 5V O 5 V DC 5 V DC power to TRSS
B4 GND - - Ground
B4 GND - - Ground
B5 BLT_SPEED I 0/3.3 V DC TRBLS: On/Off
B6 +5V O 5 V DC 5 V DC power to TRBLS
B7 TEMP I Analog TEMP signal
B8 ZIG_REV_SENS I 0/3.3 V DC TRES: On/Off
B9 GND - - Ground
B10 5V O 5 V DC 5 V DC power to TRES
B11 3.3V2 O 3.3 V DC 3.3 V DC power to TRPWB
B12 EEP_SCL2 O 0/3.3 V DC (pulse) EEPROM clock signal
B13 EEP_SDA2 I/O 0/3.3 V DC (pulse) EEPROM data signal
B14 GND - - Ground
B15 A0 - - Not used
B16 A1 - - Not used
YC4
1 GND - - Ground
Connected to
feed PWB 2
2 FEED_MOT_REM O 0/3.3 V DC PFM: On/Off
3 FEED_MOT_CLK O 0/3.3 V DC (pulse) PFM clock signal
4 FEED_MOT_RDY I 0/3.3 V DC PFM ready signal
5 FEED_MOT_DIR O 0/3.3 V DC PFM drive switch signal
6 FEED_CL1_REM O 0/24 V DC PFCL1: On/Off
7 FEED_CL2_REM O 0/24 V DC PFCL2: On/Off
8 ASIST_CL2 O 0/24 V DC ASCL2: On/Off
9 LIFT_MOT2_REM O 0/24 V DC LM2: On/Off
10 GND - - Ground
11 LIFT_MOT1_REM
1
O 0/24 V DC LM1: On/Off
12 CAS2_WID I 0/3.3 V DC PWSW2: On/Off
13 CAS2_LNG3 I 0/3.3 V DC PLSW2: On/Off
14 CAS2_LNG2 I 0/3.3 V DC PLSW2: On/Off
15 CAS2_LNG1 I 0/3.3 V DC PLSW2: On/Off
16 CAS1_WID I 0/3.3 V DC PWSW1: On/Off
Connector Pin Signal I/O Voltage Description
