Kyocera FS-C8600DN Service Manual

2MN/2N1
2-3-39
YC3
15 GND - - Ground
Connected to
engine PWB
16 EXIT_MAIN_SEN
S
O 0/3.3 V DC EFS1: On/Off
17 EXIT_FEED_SEN
S
O 0/3.3 V DC SBS: On/Off
18 SB_MOT_REM I 0/3.3 V DC EM: On/Off
19 SB_MOT_PH I 0/3.3 V DC EM control signal
20 SB_MOT_CLK I 0/3.3 V DC (pulse) EM clock signal
21 SB_MOT_PD I 0/3.3 V DC EM control signal
22 SB_MOT_DIR I 0/3.3 V DC EM drive switch signal
23 GND - - Ground
24 WT_VCONT_FUL
L
I 0/3.3 V DC WTS1 control signal
25 THOP_DIR - - Not used
26 DLP_FAN_CLR_
H
I 0/24 V DC DEVFM1: On/Off
27 DLP_FAN_CLR_L I 0/24 V DC DEVFM1: On/Off
28 WTNR_FULL O Analog WTS1 detection signal
29 WTNR_NEAR O Analog WTS2 detection signal
30 WTNR_VCONT I 0/3.3 V DC WTS2 control signal
31 GND - - Ground
32
WTNR_LED
I 0/3.3 V DC WTS1 control signal
33
THOP_MOT_Y_D
IR
- - Not used
34
THOP_MOT_C_D
IR
- - Not used
35
THOP_MOT_BK_
DIR
- - Not used
36
EXIT_SUB_SENS
O 0/3.3 V DC EFS2: On/Off
37 THOP_MOT_Bk_
REM
- - Not used
38 THOP_MOT_M_R
EM
- - Not used
39 THOP_MOT_C_R
EM
- - Not used
40 THOP_MOT_Y_R
EM
- - Not used
41 GND - - Ground
42 ENCODE_ Bk - - Not used
43 ENCODE_M - - Not used
Connector Pin Signal I/O Voltage Description

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
