Kyocera FS-C8600DN Service Manual

2MN/2N1
2-3-38
YC2
23 GND - - Ground
Connected to
engine PWB
24 EEP_SDA1 I/O 0/3.3 V DC (pulse) EEPROM data signal
25 GND - - Ground
26 TPD_Y_1 O Analog TS-Y detection signal
27 DLP_VCONT_Y_
1
I 0/3.3 V DC TS-Y control signal
28 TPD_TEMP_Y O Analog Developer thermistor Y detection sig-
nal
29 ERS_Y_REM I 0/24 V DC CL-Y: On/Off
30 DRM_INDEX_ Y O 0/3.3 V DC DRM-Y control signal
31 FRONT_OPEN O 0/3.3 V DC FRCSW: On/Off
32 GND - - Ground
33 I2C_SCL I 0/3.3 V DC (pulse) EEPROM clock signal
34 GND - - Ground
35 I2C_SDA I/O 0/3.3 V DC (pulse) EEPROM data signal
36 GND - - Ground
37 LSU_FAN_REM I 0/24 V DC LSUFM: On/Off
38 CLEAN_MOT_LO
CK
O 0/3.3 V DC WTM lock signal
39 CLEAN_MOT_RE
M
I 0/24 V DC WTM: On/Off
40 GND - - Ground
YC3
1 GND - - Ground
Connected to
engine PWB
2 WTNR_SET - - Not used
3 INTER_LOCK - - Not used
4 IH_CORE_SENS - - Not used
5 IH_CORE_MOT_
REM
- - Not used
6 IH_CORE_CLK - - Not used
7 WTNR_LED I 0/3.3 V DC (pulse) WTS1 LED emitter signal
8 IH_COIL_FAN_AL
M
O 0/3.3 V DC FUFFM alarm signal
9 IH_COIL_FAN_H I 0/24 V DC FUFFM: On/Off
10 IH_COIL_FAN_L I 0/24 V DC FUFFM: On/Off
11 EXIT_FAN I 0/24 V DC EFFM: On/Off
12 VIB_MOT__FAN I 0/24 V DC VM: On/Off
13 JUNC_SOL_REM I 0/24 V DC FSSOL: On/Off (ACT)
14 JUNC_SOL_RET I 0/24 V DC FSSOL: On/Off (RET)
Connector Pin Signal I/O Voltage Description

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
