2MN/2N1
2-3-37
Connector Pin Signal I/O Voltage Description
YC1
1 +3.3V1 I 3.3 V DC 3.3 V DC power from EPWB
Connected to
engine PWB
2 +3.3V2 I 3.3 V DC 3.3 V DC power from EPWB
3 +5V I 5 V DC 5 V DC power from EPWB
4 +24V I 24 V DC 24 V DC power from EPWB
5 +24V I 24 V DC 24 V DC power from EPWB
6 GND - - Ground
7 GND - - Ground
8 GND - - Ground
9 GND - - Ground
10 GND - - Ground
YC2
1 GND - - Ground
Connected to
engine PWB
2 DRM_INDEX_Bk O 0/3.3 V DC DRM-K control signal
3 ERS_Bk_REM I 0/24 V DC CL-K: On/Off
4 TPD_ Bk_1 O Analog TS-K detection signal
5 DLP_VCONT_Bk
_1
I 0/3.3 V DC TS-K control signal
6 TPD_TEMP_Bk O Analog Developer thermistor K detection sig-
nal
7 GND - - Ground
8 DRM_INDEX_M O 0/3.3 V DC DRM-M control signal
9 ERS_ M_REM I 0/24 V DC CL-M: On/Off
10 TPD_M_1 O Analog TS-M detection signal
11 DLP_VCONT_M_
1
I 0/3.3 V DC TS-M control signal
12 TPD_TEMP_M O Analog Developer thermistor M detection sig-
nal
13 GND - - Ground
14 DRM_INDEX_C O 0/3.3 V DC DRM-C control signal
15 ERS_C_REM I 0/24 V DC CL-C: On/Off
16 TPD_C_1 O Analog TS-C detection signal
17 DLP_VCONT_C_
1
I 0/3.3 V DC TS-C control signal
18 TPD_TEMP_C O Analog Developer thermistor C detection sig-
nal
19 GND - - Ground
20 TN_CLK I 0/3.3 V DC (pulse) Clock signal
21 GND - - Ground
22 EEP_SCL1 I 0/3.3 V DC (pulse) EEPROM clock signal
