Kyocera FS-C8600DN Service Manual

2MN/2N1
2-3-63
Connector Pin Signal I/O Voltage Description
YC1
1 GND - - Not used
Connected to
feed PWB 1
2 DU2_A I 0/24 V DC (pulse) DUM2 drive control signal
3 DU2_B I 0/24 V DC (pulse) DUM2 drive control signal
4 DU2_A/ I 0/24 V DC (pulse) DUM2 drive control signal
5 DU2_B/ I 0/24 V DC (pulse) DUM2 drive control signal
6 DU_OPEN_SW O 0/3.3 V DC DUCSW: On/Off
7 DU_CL_LOWER_
REM
I 0/24 V DC DUCL2: On/Off
8 DU_FAN - - Not used
9 24V2 I 24 V DC 24 V DC power from FPWB1
10 PRESS_RLS_RE
M2
I 0/24 V DC TRRM: On/Off
11 PRESS_RLS_RE
M1
I 0/24 V DC TRRM: On/Off
12 5V I 5 V DC 5 V DC power from FPWB1
13 PRESS_RLS_SE
NS
O 0/3.3 V DC TRRS: On/Off
14 DU_SENS O 0/3.3 V DC DUS2: On/Off
15 BELT_JAM_SENS - - Not used
16 REG_BK_SENS1
_S
- - Not used
17 REG_BK_SENS1
_P
- - Not used
18 REG_BK_LED - - Not used
YC2
1 GND - - Ground
Connected to
MP tray unit
2 MPF_LNG I 0/3.3 V DC MPPLSW: On/Off
3 5V O 5 V DC 5 V DC power to MPPLSW
4 MPF_WID3 I 0/3.3 V DC MPPWSW: On/Off
5 MPF_WID2 I 0/3.3 V DC MPPWSW: On/Off
6 GND - - Ground
7 MPF_WID1 I 0/3.3 V DC MPPWSW: On/Off
8 GND - - Ground
9 MPF_TABLE I 0/3.3 V DC MPTSW: On/Off

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
