Kyocera FS-C8600DN Service Manual

2MN/2N1
2-3-64
YC3
1 LED_3.3V3 O 3.3 V DC 3.3 V DC power to MPPLSW
Connected to
MP tray unit
2 GND - - Ground
3 MPF_PPR_SET I 0/3.3 V DC MPPS: On/Off
4 GND - - Ground
5 MPF_LIFT_UP_S
ENS
I 0/3.3 V DC MPLS1: On/Off
6 5V O 5 V DC 5 V DC power to MPLS1
7 GND - - Ground
8 MPF_LIFT_DOW
N_SENS
I 0/3.3 V DC MPLS2: On/Off
9 5V O 5 V DC 5 V DC power to MPLS1
10 GND - - Ground
11 MPF_JAM_SENS I 0/3.3 V DC MPFS: On/Off
12 5V O 5 V DC 5 V DC power to MPFS
13 MPF_CL_REM O 0/24 V DC MPPFCL: On/Off
14 24V2 O 24 V DC 24 V DC power to MPPFCL
15 MPF_LIFT_DR_A O 0/24 V DC MPLM: On/Off
16 MPF_LIFT_DR_B O 0/24 V DC MPLM: On/Off
YC7
1 24V2 - - Not used
Connected to
duplex clutch
2, duplex
cover switch
and duplex
motor 2
2 DU_CL2_REM - - Not used
3 DU_OPEN I 0/3.3 V DC DUCSW: On/Off
4 GND - - Ground
5 DU2_B/ O 0/24 V DC (pulse) DUM2 drive control signal
6 DU2_A/ O 0/24 V DC (pulse) DUM2 drive control signal
7 DU2_B O 0/24 V DC (pulse) DUM2 drive control signal
8 DU2_A O 0/24 V DC (pulse) DUM2 drive control signal
YC9
1 GND - - Ground
Connected to
duplex sen-
sor 2
2 DU_SENS I 0/3.3 V DC DUS2: On/Off
3 5V O 5 V DC 5 V DC power to DUS2
Connector Pin Signal I/O Voltage Description

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
