Kyocera FS-C8600DN Service Manual

2MN/2N1
2-3-65
YC10
1 LOOP_SENS I 0/3.3 V DC LPS: On/Off
Connected to
loop sensor
2 GND - - Ground
3 5V O 5 V DC 5 V DC power to LPS
4 3.3V - - Not used
5 REG_BK_LED - - Not used
6 GND - - Not used
7 REG_BK_SENS1
_P
- - Not used
8 REG_BK_SENS1
_S
- - Not used
9 GND - - Not used
10 BELT_JAM_SENS - - Not used
11 5V - - Not used
YC11
1 GND - - Ground
Connected to
duplex sen-
sor 1, eject
fan motor
and duplex
clutch 1
2 DU_ENTER_SEN
S
I 0/3.3 V DC DUS1: On/Off
3 5V O 5 V DC 5 V DC power to DUS1
4 EXIT_FAN_REM O 0/24 V DC EFM1: On/Off
5 24V2 O 24 V DC 24 V DC power to EFM1
6 EXIT_FAN_REM O 0/24 V DC EFM2: On/Off
7 24V2 O 24 V DC 24 V DC power to EFM2
8 24V2 - - Not used
9 DU_CL_UPPER_
REM
- - Not used
YC12
1 GND - - Ground
Connected to
feed PWB 1
2 GND - - Ground
3 MPF_TABLE O 0/3.3 V DC MPTSW: On/Off
4 MPF_WID1 O 0/3.3 V DC MPPWSW: On/Off
5 MPF_WID2 O 0/3.3 V DC MPPWSW: On/Off
6 MPF_WID3 O 0/3.3 V DC MPPWSW: On/Off
7 MPF_LNG O 0/3.3 V DC MPPLSW: On/Off
8 LED_3.3V3 I 3.3 V DC 3.3 V DC power from FPWB1
9 MPF_PPR_SET O 0/3.3 V DC MPPS: On/Off
10 MPF_LIFT_UP_S
ENS
O 0/3.3 V DC MPLS1: On/Off
Connector Pin Signal I/O Voltage Description

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
