Kyocera FS-C8600DN Service Manual

2MN/2N1
2-3-66
YC12
11 MPF_LIFT_DOW
N_SENS
O 0/3.3 V DC MPLS2: On/Off
Connected to
feed PWB 1
12 MPF_JAM_SENS O 0/3.3 V DC MPFS: On/Off
13 MPF_CL_REM I 0/24 V DC MPPFCL: On/Off
14 24V2 I 24 V DC 24 V DC power from FPWB1
15 MPF_LIFT_MOT_
A
I 0/24 V DC MPLM: On/Off
16 MPF_LIFT_MOT_
B
I 0/24 V DC MPLM: On/Off
17
24V2
- - Not used
18
ID_SOL_ACT
- - Not used
19
GND
- - Not used
20
GND
- - Not used
YC13
1 3.3V I 3.3 V DC 3.3 V DC power from FPWB1
Connected to
feed PWB 1
2 LOOP_SENS O 0/3.3 V DC LPS: On/Off
3 EDGE_FAN_REM I 0/24 V DC FUFM: On/Off
4 DU1_A I 0/24 V DC (pulse) DUM1 drive control signal
5 DU1_B I 0/24 V DC (pulse) DUM1 drive control signal
6 DU1_A/ I 0/24 V DC (pulse) DUM1 drive control signal
7 DU1_B/ I 0/24 V DC (pulse) DUM1 drive control signal
8 GND - - Ground
9 DU_CL_UPPER_
REM
I 0/24 V DC DUCL1: On/Off
10 24V2 I 24 V DC 24 V DC power from FPWB1
11 EXIT_FAN I 0/24 V DC EFM: On/Off
12 DU_ENTER_SEN
S
O 0/3.3 V DC DUS1: On/Off
YC14
1 GND - - Ground
Connected to
transfer
release sen-
sor and
transfer
release
motor
2 PRESS_RLS_SE
NS
I 0/3.3 V DC TRRS: On/Off
3 5V O 5 V DC 5 V DC power to TRRS
4 PRESS_RLS_RE
M1
O 0/24 V DC TRRM: On/Off
5 PRESS_RLS_RE
M2
O 0/24 V DC TRRM: On/Off
6 NC - - Not used
Connector Pin Signal I/O Voltage Description

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
