Kyocera FS-C8600DN Service Manual

2MN/2N1
1-3-4
High
voltage
U101 Normal B/W - 135
Add Color 2/2/5
Add Color 2nd -3/-3/-2/-14
Surround Correct Off
U106 Setting the voltage for the secondary
transfer
Light/Normal 1st
Normal2/3 1st
143/134/120 150/139/128
Light/Normal 2nd
Normal2/3 2nd
207/155/124 220/163/128
Light/Normal 1st 3/4(Gloss)
Normal2/3 1st 3/4(Gloss)
131/123/120
Light/Normal 2nd 3/4(Gloss)
Normal2/3 2nd 3/4(Gloss)
180/140/120
Light/Normal 1st B/W
Normal2/3 1st B/W
- 150/144/128/
Light/Normal 2nd B/W
Normal2/3 2nd B/W
- 183/171/128
Heavy1 1st 3/4 133/129/124
Heavy1 2nd 3/4 155/150/124
Heavy4/5 1st Half 126/123/119 130/127/122
Heavy4/5 2nd Half 144/140/119 151/146/122
OHP 134/129/124 139/133/128
Bias 1/1/1/-/138/126/133 1/1/1/1/143/130/133
U107 Setting the transfer cleaning voltage -
Belt(A) 202/180/192/- 207/182/192/212
Belt(B) 150/110/130/- 160/110/130/160
U108 Setting separation shift bias -
Output 55/55/55/55/0/0
Output 3/4 55/55/55/55
Output B/W 20/20/20/20
Timing -
Subtraction Value -35
U110 Checking the drum count -
U111 Checking the drum drive time -
U117 Checking the drum number -
U118 Displaying the drum history -
U119 Setting the drum -
Section
Item
No.
Content of maintenance item
Initial setting
45ppm 55ppm
