Kyocera FS-C8600DN Service Manual

2MN/2N1
1-3-5
High
voltage
U122 Checking the transfer belt unit number -
U123 Displaying the transfer belt unit history -
U127 Checking/clearing the transfer count -
U128 Setting transfer high-voltage timing -5/0/13 -5/0/10
Developer U130 Initial setting for the developer -
U131 Adjusting the toner sensor control volt-
age
-
Manual 150/150/150/150
Mode Auto
U132 Replenishing toner forcibly
U135 Checking toner motor operation -
U136 Setting toner near end detection 3/3
U139 Displaying the temperature and humidity
outside the machine
-
U140 Displaying developer bias
Sleeve DC 84/84/84/70/-
84/84/84/70/70
Sleeve AC 155/155/155/155/-
155/155/155/155/155
Mag DC 155/155/155/155/-
155/155/155/155/155
Mag AC 160/200/200/200/- 160/200/200/200/160
Sleeve Freq 5345/
-/
5345/
5345
5511/5345/5345/5345
Sleeve Duty 68/-
68/68
Mag Duty 43/- 43/43
AC Calib 15/15/15/12
Mode1
U147 Setting for toner applying operation
Mode Mode1
Upper Limit 2.0
Minimum 10
Interval Number 250/100/50
U148 Setting drum refresh mode 2/2
U155 Checking sensors for toner -
U156 Setting the toner replenishment level
Supply 512/512/512/512/- 512/512/512/512/512
Empty 100/100/100/100/- 100/100/100/100/100
Section
Item
No.
Content of maintenance item
Initial setting
45ppm 55ppm

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
