Kyocera FS-C8600DN Service Manual

2MN/2N1-1
1-3-6
Developer U157 Checking the developer drive time -
U158 Checking the developer count -
Fuser U161 Setting the fuser control temperature
Warm Up 165/140/80/170/165/
150/50/155
170/145/80/175/175/
150/50/160
Print 170/5 175/5
Low Power Mode Mode1
Grain Mode Mode0
U167 Checking/clearing the fuser count -
U169 Checking/setting the fuser power source -
U199 Displaying fuser heater temperature -
Operation
panel and
support
equip-
ment
U207 Checking the operation panel keys -
U208 Setting the paper size for the side deck Letter (Inch)/A4 (Metric)
U221 Setting the USB host lock function Off
U223 Operation panel lock Unlock
U234 Setting punch destination Inch (Inch)/Europe Metric (Metric)
U237 Setting finisher stack quantity 0/0
U240 Checking the operation of the finisher -
U241 Checking the operation of the switches
of the finisher
-
U246 Setting the finisher
Finisher 0/0/0/0/0/0/0/0
Booklet 0/0/0/0/0/0/0/0/0
U247 Setting the paper feed device -
Mode
setting
U250 Checking/clearing the maintenance
cycle
600000/600000/300000
U251 Checking/clearing the maintenance
counter
0/0/0
U252 Setting the destination -
U253 Switching between double and single
counts
DBL(A3/Ledger)
U260 Selecting the timing for print counting Eject
U265 Setting OEM purchaser code -
U271 Setting the page count 2/3
U278 Setting the delivery date -
U285 Setting service status page On
Section
Item
No.
Content of maintenance item
Initial setting
45ppm 55ppm

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
