Kyocera FS-C8600DN Service Manual

2MN/2N1-1
1-3-7
Mode
setting
U323 Setting abnormal temperature and
humidity warning
On
U325 Setting the paper interval Off/1
U327 Setting the cassette heater control Off
U332 Setting the size conversion factor
Rate 1.0
Mode 0
Level 1 1.0
Level 2 2.5
U340 Setting the applied mode 190/1
U345 Setting the value for maintenance due
indication
0
process-
ing
U410 Setting a Gamma table Table1
U460 Adjusting the conveying sensor
Conveying Sensor 0/0
On/Off Config Off
U464 Setting the ID correction operation
Permission On
Time Interval 480
Mode Normal
On/Sleep Out On
AP/NE On
Leaving Time 480
Driving Time 300
Timing 3600
Target Value 890/910/910/760/320/320/300/350
Print Rate(B/W) 50
Calib -
Edge Reduction Off
U465 Data reference for ID correction -
U467 Setting the color registration adjustment -
Color Regist On
Timing 10
U468 Checking the color registration data -
U469 Adjusting the color registration -
U474 Checking LSU cleaning operation 1000
U485 Setting the color table -
Section
Item
No.
Content of maintenance item
Initial setting
45ppm 55ppm

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
