Model 831 Manual Sound Recording Playback 16-21
Manual Sound Recording
Sound recordings which have been recorded manually using
the Marker function will be indicated by the text “Markers
Record” as shown in FIGURE 16-27.
FIGURE 16-27 Manual Sound Record
Measurement Sound Recording
Sound recordings implemented automatically at the
beginning of Measurement History periods are identified by
the text “Measurement Record” as shown in FIGURE 16-28.
FIGURE 16-28 Measurement Sound Record
Noise Event Sound Recording
Sound recordings implemented automatically as a result of
noise events are identified by the text “Event Record” as
shown in FIGURE 16-29.
FIGURE 16-29 Noise Event Sound Record
Combined Recording
A combined sound recording, described in "Combined
Sound Recordings" on page 16-19, is identified by the
recording type of the first recording which initiated the
recording process.
