Model 831 Manual Preferences 18-13
Jack Function
The AC/DC Out/Headset Jack on the bottom of the
instrument can be configured to provide one of the
following:
• As an AC/DC output of the signal from the detector. Use
with the optional AC/DC Output Cable (CLBL139); AC
signal is output via the red BNC and DC signal via the
white BNC. The AC output is typically directed to a
frequency analyzer or oscilloscope and the DC output is
typically directed to a strip chart recorder.
• As a microphone and speaker connection when used with
the optional headset for voice recording/playback
(ACC003)
It can also be set to Off.
Run Mode Type of Stop Auto-Store Preference
Prompt Store
Timed Stop
Timer-activated final
stop
Prompts when timer
is complete
File automatically stored
Manually-activated
(stop key)
No action performed No action performed
Stop When
Stable
Timer-activated stop Prompts when stable File automatically stored
Manually-activated
(stop key)
Prompts when
stopped
File automatically stored
Single Block
Timer
Timer-activated stop
Prompts when timer
complete
File automatically stored
Manually-activated
(stop key)
Prompts when
stopped
File automatically stored
Daily Timer
Timer-activated final
stop
No prompt; file auto-
matically stored
File automatically stored
Manually-activated
(stop key)
No action performed No action performed
Table 18 - 1 Run Mode Behavior
