4-6 Setup Tabs Model 831 Manual
The effect on the A-Weighted linearity range is shown in the
section “f) Linear Operating Range” on page B-9.
Octave Band Analyzer Tab (Optional)
The default values for these
parameters are as shown in
FIGURE 4-5.
This tab will only appear when the Model 831 has the
optional 831-OB3 firmware enabled.
FIGURE 4-5 OBA Tab
OBA Parameter Selection
The OBA parameters are selected as shown in FIGURE 4-6.
FIGURE 4-6 OBA Parameter Selection
Highlight and Press 5
Key to Select
