LSI Corporation
- 268 -
12Gb/s MegaRAID SAS Software User Guide
March 2014
Chapter 9: Configuration
Creating a New Configuration
Figure 159 Span 0 of Drive Group 0
d. Click Create Span to create a second span in the drive group.
e. Select unconfigured drives from the list of drives, and click Add> to add them to the second drive group.
The selected drives appear under Span 1 below Drive Group 0, as shown in the following figure.
