C.5 RAID Configuration Commands
Table 74 RAID Configuration Commands
Description MegaCLI Command StorCLI Command
Create a RAID configuration of
RAID type 0, 1, 5, and 6.
MegaCli –CfgLDAdd
-R0|-R1|-R5|-R6[E0:S0,E1:S1,...]
[WT | WB] [NORA | RA | ADRA]
[Direct | Cached]
[CachedBadBBU|NoCachedBadBBU]
[-szXXXXXXXX [-szYYYYYYYY [... ]]]
[-strpszM] [–Hsp[E5:S5,...]]
[–afterLdX] -aN
storcli /cx add vd type=raid[0|1|5|6]
[Size=<VD1_Sz>,< VD2_Sz>,..|*all]
[name=<VDNAME1>,..]
drives=e:s|e:s-x|e:s-x,y;e:s-x,y,z [PDpe
rArray=x]
[SED] [pdcache=on|off|*default][pi]
[DimmerSwitch(ds)=default|automatic(auto
)|*none|maximum(max)
|MaximumWithoutCaching(maxnocache)]
[wt|*wb|awb] [nora|*ra] [*direct|cached]
[strip=<8|16|32|64|128|256|512|1024]
[AfterVd=X]
[Spares=[e:]s|[e:]s-x|[e:]s-x,y] [force]
Create a CacheCade virtual drive. MegaCLI -CfgCacheCadeAdd [-rX]
-Physdrv[E0:S0,...] {-Name
LdNamestring} [WT|WB|ForcedWB]
[-assign -LX|L0,2,5..|LALL]
-aN|-a0,1,2|-Aall
storcli /cx add vd cachecade|cc
Type=raid[0,1,10]
drives=[e:]s|[e:]s
-x|[e:]s-x,y [ < WT|
WB> ] [assignvds=0,1,2]e:]
Create a RAID configuration of
RAID type 10, 50, and 60.
MegaCli –CfgSpanAdd
-aN|-a0,1,2|-aALL -R10|-R50|R60
–Array0[E0:S0,E1:S1,...]
–Array1[E0:S0,E1:S1,...] [...] [WT
| WB] [NORA | RA | ADRA] [Direct |
Cached]
[CachedBadBBU|NoCachedBadBBU]
[-szXXXXXXXX[-szYYYYYYYY [... ]]]
[-strpszM] [–afterLdX] -aN
storcli /cx add vd type=raid[10|50|60]
[Size=<VD1_Sz>,<VD2_Sz>,..|*all] [name=<
VDNAME1>,..]
drives=e:s|e:s-x|e:s-x,y;e:s-x,y,z [PDpe
rArray=x]
[SED] [pdcache=on|off|*default][pi]
[DimmerSwitch(ds)=default|automatic(auto
)|*none|maximum(max)
|MaximumWithoutCaching(maxnocache)]
[wt|*wb|awb] [nora|*ra] [*direct|cached]
[strip=<8|16|32|64|128|256|512|1024]
[AfterVd=X]
[Spares=[e:]s|[e:]s-x|[e:]s-x,y] [force]
Clear the complete configuration. MegaCli -CfgClr [-Force]
-aN|-a0,1,2|-aALL
storcli /c0/vall delete [force]
Show the topology information
of the drive group.
MegaCLI -CfgDsply
-aN|-a0,1,2|-Aall
storcli /cx/dall show [all]
Show information for a
CacheCade virtual drive.
MegaCLI -CfgCacheCadeDsply
-aN|-a0,1,2|-Aall
storcli /cx/dall show CacheCade(cc)
Delete a virtual drive hosting the
operating system.
MegaCLI -CfgLdDel
-LX|-L0,2,5...|-LALL [-Force]
-aN|-a0,1,2|-aALL
storcli /cx/v/vx [all] delete -force
Delete a CacheCade virtual drive. MegaCLI -CfgCacheCadeDel
-LX|-L0,2,5...|-LALL
-aN|-a0,1,2|-Aall
storcli /cx/vx [all] delete
CacheCade(cc)
Show, delete, and import the
foreign configuration commands.
MegaCli –CfgForeign –Scan |
{-Preview | –Dsply| -Import |
-Clear[FID]} -aN|-a0,1,2|-aALL"
storcli /cx/f(x|all) show [all]
[securityKey=xxx]
storcli /cx/f(x|all) del|delete
[securityKey=xxx]
storcli /cx/f(x|all) import [preview]
[securityKey=xxx]"
