Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1001
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00838
C00837/139 L_Curve_2
: nIn_a
C00837/140 L_Curve_3
: nIn_a
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00837 | 16-bit inputs [incr./ms] (Set2)
Data type: INTEGER_16
Index: 23738
d
= 5CBA
h
Parameter | Name:
C00838 | Binary inputs (Set2)
Data type: UNSIGNED_8
Index: 23737
d
= 5CB9
h
Display of the signal status of the binary inputs of different blocks
• In addition to the parameter C00833
.
• Non-listed subcodes are "reserved".
Selection list
0 False
1 True
Subcodes Info
C00838/1 L_And5_1
: bIn1
C00838/2 L_And5_1
: bIn2
C00838/3 L_And5_1
: bIn3
C00838/4 L_And5_1
: bIn4
C00838/5 L_And5_1
: bIn5
C00838/6 L_And5_2
: bIn1
C00838/7 L_And5_2
: bIn2
C00838/8 L_And5_2
: bIn3
C00838/9 L_And5_2
: bIn4
C00838/10 L_And5_2
: bIn5
C00838/11 L_AnalogSwitch_4
: bSet
C00838/12 L_AnalogSwitch_5
: bSet
C00838/13 L_DFlipFlop_2: bD
C00838/14 L_DFlipFlop_2
: bClk
C00838/15 L_DFlipFlop_2: bClr
C00838/16 L_DigitalDelay_2
: bIn
C00838/17 L_DigitalDelay_3
: bIn
C00838/18 L_PhaseIntK_1: bLoad
C00838/19 L_PhaseIntK_2
: bLoad
C00838/20 L_DigitalLogic_2
: bIn1
C00838/21 L_DigitalLogic_2
: bIn2
C00838/22 L_DigitalLogic_2
: bIn3
C00838/23 L_DigitalLogic5_1
: bIn1
C00838/24 L_DigitalLogic5_1
: bIn2
C00838/25 L_DigitalLogic5_1
: bIn3
C00838/26 L_DigitalLogic5_1
: bIn4
C00838/27 L_DigitalLogic5_1
: bIn5
C00838/28 L_DigitalLogic5_2
: bIn1
C00838/29 L_DigitalLogic5_2
: bIn2
C00838/30 L_DigitalLogic5_2
: bIn3
