Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1045
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01053
C01054
C01055
C01056
Parameter | Name:
C01053 | L_ProcessCtrl_1: Controller times
Data type: UNSIGNED_16
Index: 23522
d
= 5BE2
h
From version 11.00.00
Setting range (min. value | unit | max. value)
0.000 s 30.000
Subcodes Lenze setting Info
C01053/1 0.000 s L_ProcessCtrl_1
: Acceleration/deceleration time
C01053/2 0.000 s L_ProcessCtrl_1
: Filter time constant
C01053/3 0.000 s L_ProcessCtrl_1
: Rate time
C01053/4 1.000 s L_ProcessCtrl_1
: Reset time
C01053/5 0.000 s L_ProcessCtrl_1
: Rate action
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1000
Parameter | Name:
C01054 | L_ProcessCtrl_1: System deviation
Data type: INTEGER_16
Index: 23521
d
= 5BE1
h
From version 11.00.00
Setting range (min. value | unit | max. value)
0.00 % 199.99
Subcodes Lenze setting Info
C01054/1 100.00 % L_ProcessCtrl_1
: Gain of system deviation
C01054/2 0.00 % L_ProcessCtrl_1
: Area of system deviation
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C01055 | L_ProcessCtrl_1: Correcting variable limitation
Data type: UNSIGNED_8
Index: 23520
d
= 5BE0
h
From version 11.00.00
Selection list
0False
1True
Subcodes Lenze setting Info
C01055/1 0: FALSE L_ProcessCtrl_1
: Correcting variable limitation
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C01056 | L_ProcessCtrl_1: Controller gain
Data type: UNSIGNED_16
Index: 23519
d
= 5BDF
h
From version 11.00.00
Setting range (min. value | unit | max. value)
0.00 100.00
Subcodes Lenze setting Info
C01056/1 0.10 L_ProcessCtrl_1
: Controller gain
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
