Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1047
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01061
C01062
C01063
C01060/3 1.000 s L_PosCtrlLin_1
: Deceleration ramp
C01060/4 1.000 s L_PosCtrlLin_2
: Deceleration of set position
C01060/5 1.000 s L_PosCtrlLin_2
: Acceleration ramp
C01060/6 1.000 s L_PosCtrlLin_2
: Deceleration ramp
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1000
Parameter | Name:
C01060 | L_PosCtrlLin 1-2: Ramps
Data type: INTEGER_32
Index: 23515
d
= 5BDB
h
Parameter | Name:
C01061 | L_PosCtrlLin 1-2: Traversing speeds
Data type: INTEGER_16
Index: 23514
d
= 5BDA
h
From version 11.00.00
Setting range (min. value | unit | max. value)
-15000 rpm 15000
Subcodes Lenze setting Info
C01061/1 199 rpm L_PosCtrlLin_1
: Forward motion
C01061/2 199 rpm L_PosCtrlLin_1
: Return motion
C01061/3 199 rpm L_PosCtrlLin_2
: Forward motion
C01061/4 199 rpm L_PosCtrlLin_2
: Return motion
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C01062 | L_SwitchPoint_1: Dead time
Data type: UNSIGNED_16
Index: 23513
d
= 5BD9
h
From version 11.00.00
Setting range (min. value | unit | max. value)
0 65535
Subcodes Lenze setting Info
C01062/1 0 L_SwitchPoint_1
: Dead time 1
C01062/2 0 L_SwitchPoint_1
: Dead time 2
C01062/3 0 L_SwitchPoint_1: Dead time 3
C01062/4 0 L_SwitchPoint_1
: Dead time 4
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C01063 | L_SwitchPoint_1: Hysteresis
Data type: UNSIGNED_16
Index: 23512
d
= 5BD8
h
From version 11.00.00
Setting range (min. value | unit | max. value)
0 Incr. 65535
Subcodes Lenze setting Info
C01063/1 0 incr. L_SwitchPoint_1
: Hysteresis 1
C01063/2 0 incr. L_SwitchPoint_1
: Hysteresis 2
C01063/3 0 incr. L_SwitchPoint_1
: Hysteresis 3
C01063/4 0 incr. L_SwitchPoint_1
: Hysteresis 4
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
