Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1053
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01079
C01080
C01081
C01082
Parameter | Name:
C01079 | L_DFRFG_1: Synchronisation window
Data type: UNSIGNED_16
Index: 23496
d
= 5BC8
h
From version 11.00.00
Setting range (min. value | unit | max. value)
0 Incr. 65535
Subcodes Lenze setting Info
C01079/1 100 incr. L_DFRFG_1
: Synchronisation window (position)
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C01080 | L_DFRFG_1: Offset
Data type: INTEGER_32
Index: 23495
d
= 5BC7
h
From version 11.00.00
Setting range (min. value | unit | max. value)
-2147483647 Incr. 2147483647
Subcodes Lenze setting Info
C01080/1 0 incr. L_DFRFG_1
: Offset
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C01081 | L_DFRFG_1: Sync. direction / TP function
Data type: UNSIGNED_8
Index: 23494
d
= 5BC6
h
From version 11.00.00
Selection list
1 cw/ccw - without TP
2 cw - without TP
3ccw - without TP
4 cw/ccw - with TP
5 cw - with TP
6ccw - with TP
Subcodes Lenze setting Info
C01081/1 1: cw/ccw - without TP L_DFRFG_1
: Sync. direction / TP function
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C01082 | LS_WriteParamList: Execute Mode
Data type: UNSIGNED_8
Index: 23493
d
= 5BC5
h
From version 04.00.00
Parameter change-over
: Selection of the activation method
Selection list (Lenze setting printed in bold) Info
0by Execute The writing of the parameter list is activated by a FALSE/
TRUE edge at the bExecute input.
1 by Input Select The writing of the parameter list is carried out if a change
is made at the select inputs and if the inverter is
initialised.
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
