15 Parameter reference
15.2 Parameter list
1052
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01076
C01077
C01078
Selection list
0Inactive
1 Permanent sync. without enable
(bZeroPulse)
2 Permanent sync. with enable
(bZeroPulse)
10 1x sync. - Angular diff. shortest path
setpoint
11 1x Sync. - Angular diff. Cw
12 1x Sync. - Angular diff. Ccw
13 1x Sync. - Angular diff. shortest path
act. value
Subcodes Lenze setting Info
C01075/1 0: Inactive L_DFSET_1
: Synchronisation mode
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C01075 | L_DFSET_1: Synchronisation mode
Data type: UNSIGNED_8
Index: 23500
d
= 5BCC
h
Parameter | Name:
C01076 | L_DFRFG_1: Times
Data type: UNSIGNED_32
Index: 23499
d
= 5BCB
h
From version 11.00.00
Setting range (min. value | unit | max. value)
0.000 s 999.900
Subcodes Lenze setting Info
C01076/1 1.000 s L_DFRFG_1
: Acceleration and deceleration time
C01076/2 0.000 s L_DFRFG_1
: Deceleration time for quick stop
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1000
Parameter | Name:
C01077 | L_DFRFG_1: Max. speed-up
Data type: INTEGER_16
Index: 23498
d
= 5BCA
h
From version 11.00.00
Setting range (min. value | unit | max. value)
1 rpm 15000
Subcodes Lenze setting Info
C01077/1 3000 rpm L_DFRFG_1
: Max. speed-up
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C01078 | L_DFRFG_1: Following error
Data type: UNSIGNED_32
Index: 23497
d
= 5BC9
h
From version 11.00.00
Setting range (min. value | unit | max. value)
10 Incr. 2000000000
Subcodes Lenze setting Info
C01078/1 2000000000 incr. L_DFRFG_1
: Following error limit
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
