Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1057
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01092
C01093
Parameter | Name:
C01092 | LS_ParReadWrite 1-6: FailState
Data type: UNSIGNED_16
Index: 23483
d
= 5BBB
h
From version 04.00.00
Error status:
• 0 = no error
• 33803 | 0x840B = invalid data type (e.g. STRING)
• 33804 | 0x840C = limit violation
• 33806 | 0x840E = invalid code
• 33813 | 0x8415 = no element of the selection list
• 33815 | 0x8417 = writing of the parameter not permitted
• 33816 | 0x8418 = writing of the parameter only permitted if controller is inhibited
• 33829 | 0x8425 = invalid subcode
• 33865 | 0x8449 = no parameter with subcodes
Display range (min. value | unit | max. value)
0 34000
Subcodes Info
C01092/1 LS_ParReadWrite_1
: Error status
C01092/2 LS_ParReadWrite_2
: Error status
C01092/3 LS_ParReadWrite_3
: Error status
C01092/4 LS_ParReadWrite_4
: Error status
C01092/5 LS_ParReadWrite_5
: Error status
C01092/6 LS_ParReadWrite_6
: Error status
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01093 - LS_ParReadWrite 1-6: Arithmetic mode
Data type: UNSIGNED_8
Index: 23482
d
= 5BBA
h
From version 06.00.00
The integrated arithmetic function
allows for easy arithmetic conversion of the process value to be written or which
was read into the format of the target parameter via parameterisable factors and without the need for an
additional arithmetic FB.
Selection list
0 No arithmetic
1 In16Bit: LW=+/-32767
2 In16Bit: HW=+/-; LW=0..65535
3 In32Bit: HW_LW=+/-2147483647
Subcodes Lenze setting Info
C01093/1 0: no arithmetic LS_ParReadWrite_1
: Arithmetic mode
C01093/2 0: no arithmetic LS_ParReadWrite_2
: Arithmetic mode
C01093/3 0: no arithmetic LS_ParReadWrite_3
: Arithmetic mode
C01093/4 0: no arithmetic LS_ParReadWrite_4
: Arithmetic mode
C01093/5 0: no arithmetic LS_ParReadWrite_5
: Arithmetic mode
C01093/6 0: no arithmetic LS_ParReadWrite_6
: Arithmetic mode
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
