15 Parameter reference
15.2 Parameter list
1058
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01094
C01095
C01098
Parameter | Name:
C01094 - LS_ParReadWrite 1-6: Numerator
Data type: INTEGER_16
Index: 23481
d
= 5BB9
h
From version 06.00.00
Arithmetic function
: Factor (numerator) for internal conversion in arithmetic modes 1 ... 3.
Setting range (min. value | unit | max. value)
-32767 32767
Subcodes Lenze setting Info
C01094/1 1 LS_ParReadWrite_1
: Numerator
C01094/2 1 LS_ParReadWrite_2
: Numerator
C01094/3 1 LS_ParReadWrite_3
: Numerator
C01094/4 1 LS_ParReadWrite_4
: Numerator
C01094/5 1 LS_ParReadWrite_5
: Numerator
C01094/6 1 LS_ParReadWrite_6
: Numerator
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01095 - LS_ParReadWrite 1-6: Denominator
Data type: INTEGER_16
Index: 23480
d
= 5BB8
h
From version 06.00.00
Arithmetic function
: Factor (denominator) for internal conversion in arithmetic modes 1 ... 3.
Setting range (min. value | unit | max. value)
1 32767
Subcodes Lenze setting Info
C01095/1 1 LS_ParReadWrite_1
: Denominator
C01095/2 1 LS_ParReadWrite_2
: Denominator
C01095/3 1 LS_ParReadWrite_3
: Denominator
C01095/4 1 LS_ParReadWrite_4: Denominator
C01095/5 1 LS_ParReadWrite_5
: Denominator
C01095/6 1 LS_ParReadWrite_6
: Denominator
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01098 | LS_ParReadWrite 1-6: Configuration
Data type: UNSIGNED_16
Index: 23477
d
= 5BB5
h
Setting range (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 Keeping the value
Bit 1 Keeping the value in the event of an
error
Bit 2 Reserved
Bit 3 Reserved
Bit 4 Reserved
Bit 5 Reserved
Bit 6 Reserved
