Lenze 8400 - Page 1059

Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1059
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01100
C01101
Bit 7 Reserved
Bit 8 Reserved
Bit 9 Reserved
Bit 10 Reserved
Bit 11 Reserved
Bit 12 Reserved
Bit 13 Reserved
Bit 14 Reserved
Bit 15 Reserved
Subcodes Lenze setting Info
C01098/1 0x0000 LS_ParReadWrite_1
: Configuration
C01098/2 0x0000 LS_ParReadWrite_2
: Configuration
C01098/3 0x0000 LS_ParReadWrite_3
: Configuration
C01098/4 0x0000 LS_ParReadWrite_4
: Configuration
C01098/5 0x0000 LS_ParReadWrite_5
: Configuration
C01098/6 0x0000 LS_ParReadWrite_6
: Configuration
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C01098 | LS_ParReadWrite 1-6: Configuration
Data type: UNSIGNED_16
Index: 23477
d
= 5BB5
h
Parameter | Name:
C01100 | Function L_Counter 1-3
Data type: UNSIGNED_8
Index: 23475
d
= 5BB3
h
Selection of reset function
Selection list
0Normal counting
1Auto reset
2Manual reset
Subcodes Lenze setting Info
C01100/1 0: Normal counting L_Counter_1
: Function
C01100/2 0: Normal counting L_Counter_2
: Function
C01100/3 0: Normal counting L_Counter_3: Function
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01101 | Comparison L_Counter 1-3
Data type: UNSIGNED_8
Index: 23474
d
= 5BB2
h
From version 05.00.00
Selection of comparison operation
Selection list
0 Greater than or equal to
1 Less than or equal to
2equal to
