Lenze 8400 - Page 1060

15 Parameter reference
15.2 Parameter list
1060
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01108
C01120
Subcodes Lenze setting Info
C01101/1 0: Greater than or equal to L_Counter_1
: Comparison
C01101/2 0: Greater than or equal to L_Counter_2
: Comparison
C01101/3 0: Greater than or equal to L_Counter_3
: Comparison
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01101 | Comparison L_Counter 1-3
Data type: UNSIGNED_8
Index: 23474
d
= 5BB2
h
Parameter | Name:
C01108 | L_SwitchPoint_1: Dead time factor
Data type: UNSIGNED_8
Index: 23467
d
= 5BAB
h
From version 14.00.00
Selection list
11μs
210μs
3 100 μs
4 1000 μs
Subcodes Lenze setting Info
C01108/1 2: 10 μs L_SwitchPoint_1
: Deadtime factor 1
C01108/2 2: 10 μs L_SwitchPoint_1
: Deadtime factor 2
C01108/3 2: 10 μs L_SwitchPoint_1
: Deadtime factor 3
C01108/4 2: 10 μs L_SwitchPoint_1
: Deadtime factor 4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01120 | Sync signal source
Data type: UNSIGNED_8
Index: 23455
d
= 5B9F
h
From version 02.00.00
Selection of the signal source for device synchronisation
• The drive can only be synchronised by one source.
Synchronisation of the internal time base
Selection list (Lenze setting printed in bold) Info
0Off Synchronisation off
1 CAN on board Synchronisation via CAN bus
Sync telegram
4 MCI Synchronisation via MCI (communication module)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
