Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1071
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01219
C01220
Bit 4  Reserved
Bit 5  Reserved
Bit 6  Reserved
Bit 7  Position controller off 1 ≡ Position controller is deactivated. Thus, the
compensation of the following error is switched off.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C01218 | MCK: Position follower setting
Data type: UNSIGNED_8
Index: 23357
d
= 5B3D
h
Parameter | Name:
C01219 | MCK: Speed follower setting
Data type: UNSIGNED_8
Index: 23356
d
= 5B3C
h
Settings for "Speed follower" mode
Speed follower
Setting range (min. hex value | max. hex value) Lenze setting
0x00 0xFF 0x0C (decimal: 12)
Value is bit-coded: ( =bit set) Info
Bit 0  Reserved
Bit 1  Reserved
Bit 2  HW limit switch on 1 ≡ Travel range monitoring via hardware limit switch is
active. The error response can be parameterised in
C00595/1
and C00595/2.
Bit 3  SW limit switch on 1 ≡ Travel range monitoring via parameterised software
limit positions is active. The error response can be
parameterised in C00595/3
and C00595/4.
Bit 4  Reserved
Bit 5  Reserved
Bit 6  Reserved
Bit 7  Position controller off 1 ≡ Position controller is deactivated. Thus, the
compensation of the following error is switched off.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C01220 | MCK: Ref. setting
Data type: UNSIGNED_16
Index: 23355
d
= 5B3B
h
From version 14.00.00
Settings for "homing" mode
Homing
Setting range (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 Reserved
Bit 1 Reserved
Bit 2 Reserved
Bit 3 Reserved
Bit 4 Start deletes bHomePosAvailable 1 ≡ When homing is started (mode 4 ... 15), the reference
information is deleted.
