Lenze 8400 - Page 1083

Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1083
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01245
C01246
Subcodes Lenze setting Info
C01244/1 100 ms MCK: Dwell time - target position
• Time expiring after reaching the setpoint position for
positioning processes and enabling the actual
position detection in the target position window.
Target position monitoring
C01244/2 0 ms MCK: Waiting time following error 1
• From version 11.00.00
Following error monitoring system
C01244/3 0 ms MCK: Waiting time following error 2
• From version 11.00.00
Following error monitoring system
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01244 | MCK: Target detection - times
Data type: UNSIGNED_16
Index: 23331
d
= 5B23
h
Parameter | Name:
C01245 | MCK: Target detection - positions
Data type: INTEGER_32
Index: 23330
d
= 5B22
h
From version 02.00.00
Position settings for various MCK functions
Setting range (min. value | unit | max. value)
0.0000 units 214748.3647
Subcodes Lenze setting Info
C01245/1 1.0000 units MCK: Window target position
• Window around the target position for comparison
with the actual position to see whether the drive is in
target.
Target position monitoring
C01245/2 1.0000 units MCK: Blocking zone Modulo
• From version 06.00.00
Activation of the Modulo measuring system
C01245/3 0.0000 units MCKI: Hysteresis position change
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
Parameter | Name:
C01246 | MCK: Select signal source
Data type: UNSIGNED_8
Index: 23329
d
= 5B21
h
From version 06.00.00
Selection of the touch probe signal source for reference search with touch probe detection
• If the reference signal is to follow a real touch probe, the Touch-Probe-Interface
must be configured accordingly.
Homing
