Lenze 8400 - Page 1087

Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1087
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01294
C01295
C01296
Parameter | Name:
C01294 | Mode: Position calculation
Data type: UNSIGNED_8
Index: 23281
d
= 5AF1
h
From version 12.00.00
Selection of the conversion mode
Selection list
0 dnOut_p=ConvWordsToDInt(HW_L
W)
1 16 bits: LW=+/-32767
2 16 bits: HW=+/-; LW=0..65535
3 32Bit: HW_LW=+/-214748.3647
Subcodes Lenze setting Info
C01294/1 0:
dnOut_p=ConvWordsToDInt(HW_L
W)
L_ConvUnitsToIncr_1
: PosCalcMode
C01294/2 0:
dnOut_p=ConvWordsToDInt(HW_L
W)
L_ConvUnitsToIncr_2
: PosCalcMode
C01294/3 0:
dnOut_p=ConvWordsToDInt(HW_L
W)
L_ConvUnitsToIncr_3
: PosCalcMode
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01295 | L_MCKStateInterface_1: Pos. selection
Data type: UNSIGNED_8
Index: 23280
d
= 5AF0
h
From version 04.00.00
Selection of the position to be provided at the dnPosOut_p output of the FB L_MckStateInterface
Selection list (Lenze setting printed in bold)
0dnPosIn_p
1 Current feed
2dnSetPos_p
3 dnActPos_p
4dnDeltaPos_p
5dnTargetPos_p
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01296 | Mode: Position calculation
Data type: UNSIGNED_8
Index: 23279
d
= 5AEF
h
From version 04.00.00
MCKInterface
