15 Parameter reference
15.2 Parameter list
1088
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01297
Selection list
0 dnPosOut_p=dnPosIn_p
1 16 bits: LW=+/-32767
2 16 bits: HW=+/-; LW=0..65535
3 32Bit: HW_LW=+/-214748.3647
Subcodes Lenze setting Info
C01296/1 0: dnPosOut_p=dnPosIn_p L_MckCtrlInterface_1
: PosCalcMode
C01296/2 1: 16Bit: LW=+/-32767 L_MckStateInterface_1
: PosDisplayMode
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01296 | Mode: Position calculation
Data type: UNSIGNED_8
Index: 23279
d
= 5AEF
h
Parameter | Name:
C01297 | L_MckCtrlInterface_1: Alternative function
Data type: UNSIGNED_8
Index: 23278
d
= 5AEE
h
Selection of the alternative function for bit 16 (PosExecute) in the MCK control word
Alternative functions for "PosExecute" control bit
Setting range (min. hex value | max. hex value) Lenze setting
0x00 0xFF 0x03 (decimal: 3)
Value is bit-coded: ( =bit set) Info
Bit 0  PosStop with PosExecute = FALSE 1 ≡ Abort positioning with PosExecute
• PosExecute="0" stops a running positioning process
by ramp-down to standstill.
Bit 1  HomingStartStop with PosExecute 1 ≡ Start/stop homing with PosExecute
• PosExecute="1" starts homing, PosExecute="0" stops
homing in the "Homing" mode.
Bit 2  SetProfilPosition with PosExecute 1 ≡ Teach set position with PosExecute
• PosExecute="0->1" accepts the setpoint position at
the MCK in the profile with the specified profile
number.
Bit 3  SetProfilPosition at position change 1 ≡ Automatic acceptance of set position
• The set position pending at the MCKInterface is
automatically transferred to the profile with the
preset profile number if a data change at the
corresponding input for the setpoijnt is detected.
Bit 4  Profile start at position change From version 11.00.00
1 ≡ Automatic profile start at position change
• An automatic PosExecute takes place if the
incremental position selection changes and this
change is higher than set in the hysteresis for position
change (C01245/3
).
Bit 5  Reserved
Bit 6  Reserved
Bit 7  Reserved
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
