15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01298
C01299
Parameter | Name:
C01298 | MCK: Operating mode change with profile no.
Data type: UNSIGNED_8
Index: 23277
d
= 5AED
h
FB L_MckCtrlInterface_1: Assignment of an operating mode to a profile
Selection list Info
0 Op.Mode inputs There will be no changed operating mode when the
profile is changed. Instead, the operating mode
requested "from outside" via the MCK control word
applies.
1 Speed follower Change to the "Speed follower" mode
2 Homing Change to the "Homing" mode
3 Manual jog Change to the "Manual jog" mode
4 Positioning Change to the "Positioning" mode
5 Stop Change to the "Stop" mode
6 Position follower Change to the "Position follower" mode
Subcodes Lenze setting Info
C01298/1 1: Speed follower MCK operating mode at profile no. 0
• Selection of the operating mode for profile 0 at
L_MckCtrlInterface_1.
C01298/2 2: Homing MCK operating mode at profile no. 1
• Selection of the operating mode for profile 1 at
L_MckCtrlInterface_1.
C01298/3 3: Manual jog MCK operating mode at profile no. 2
• Selection of the operating mode for profile 2 at
L_MckCtrlInterface_1.
C01298/4 4: Positioning MCK operating mode at profile no. 3...15
• Selection of the operating mode for profile 3 ... 15 at
L_MckCtrlInterface_1.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01299 | MCKI: Status MCKInterface
Data type: UNSIGNED_8
Index: 23276
d
= 5AEC
h
FB L_MckCtrlInterface_1: Status messages
Display area (min. hex value | max. hex value)
0x00 0xFF
Value is bit-coded: Info
Bit 0 InvalidOperationMode Invalid operating mode selection
•1 ≡ The selected operating mode is not defined/
invalid.
Bit 1 InvalidPosMode Invalid positioning mode selection
•1 ≡ The selected positioning mode is not defined/
invalid.
Bit 2 InvalidProfileNo Invalid profile number selection
•1 ≡ The selected profile number refers to a profile data
set that does not exist.
Bit 3 Reserved
