Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1093
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01306
C01307
C01308
Parameter | Name:
C01306 | Profile data: S-ramp time
Data type: UNSIGNED_16
Index: 23269
d
= 5AE5
h
Selection of the S-ramp times for profiles 1 ... 15
• The maximum S-ramp time is the time in which the maximum acceleration or the maximum deceleration is
reached along a ramp (jerk limitation).
Profile entry
Setting range (min. value | unit | max. value)
0.000 s 10.000
Subcodes Lenze setting Info
C01306/1 0.000 s Profiles 1 ... 15: S-ramp time
C01306/...
C01306/15
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
Parameter | Name:
C01307 | Profile data: Sequence profile
Data type: UNSIGNED_8
Index: 23268
d
= 5AE4
h
Selection of the sequence profile numbers for profiles 1 ... 15
• For profile linkage
Profile entry
Setting range (min. value | unit | max. value)
015
Subcodes Lenze setting Info
C01307/1 0 Profiles 1 ... 15: Sequence profile
C01307/...
C01307/15
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01308 | Profile data: TP profile
Data type: UNSIGNED_8
Index: 23267
d
= 5AE3
h
From version 06.00.00
Selection of the touch-probe profile numbers for profile 1 ... 15
• Only relevant for positioning modes with touch-probe.
Profile entry
Setting range (min. value | unit | max. value)
015
Subcodes Lenze setting Info
C01308/1 0 Profile 1 ... 15: TP profile
C01308/...
C01308/15
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
