Lenze 8400 - Page 1094

15 Parameter reference
15.2 Parameter list
1094
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01309
C01350
C01351
Parameter | Name:
C01309 | Profile data: TP signal source
Data type: UNSIGNED_8
Index: 23266
d
= 5AE2
h
From version 06.00.00
Selection of the touch-probe signal sources for profile 1 ... 15
• Only relevant for positioning modes with touch-probe.
Profile entry
Selection list
3TP-DigIn3
4TP-DigIn4
5TP-DigIn5
6TP-DigIn6
7TP-DigIn7
Subcodes Lenze setting Info
C01309/1 3: TP-DigIn3 Profiles 1 ... 15: Sequence profile
C01309/...
C01309/15
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01350 | ACDrive: Drive mode
Data type: UNSIGNED_8
Index: 23225
d
= 5AB9
h
Selection list
1 Speed mode
3Torque mode
Subcodes Lenze setting Info
C01350/1 1: Speed mode ACDrive: Drive mode
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01351 | ACDrive: Control word
Data type: UNSIGNED_16
Index: 23224
d
= 5AB8
h
From version 13.00.00
Display of the "AC Drive Profile" control word for the inverter
• Detailed information on the "AC Drive Profile" can be found in the EtherNet/IP™ communication manual.
Actuating drive speed (AC Drive Profile)
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 Run Forward Relationships between Run1 and Run2 and trigger
events can be found in the chapter "Run/Stop Event
".
Bit 1 Run Backward
Bit 2 Fault Reset 0->1 ≡ Reset error
0 ≡ No response
Bit 3 Reserved
Bit 4 Reserved
Bit 5 NetCtrl Run/Stop control:
0 ≡ via local setting in the device or terminal
1 ≡ via fieldbus (e.g. by the scanner)
